Air conditioner drain pipe PE tube flexible drain tube extension soft tube and injection connecter cheap Bentoject

FOB Reference Price:Get Latest Price
US $2-4 / Meters | 500 Meter/Meters (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Beijing, China (Mainland)
Brand Name:
LW
Model Number:
lw-8
color:
black;white;green;red;yellow...
Type:
Other Waterproofing Materials
Supply Ability
Supply Ability:
5000 Meter/Meters per Month
Packaging & Delivery
Packaging Details
20meter in a roll,a roll in a carton.
Port
Tianjin/Shanghai
Lead Time :
receive deposit after 5 days

Introduction:

 LW Re-inject Is one of the specially designed solid PVC injection pipe systems. It can be mounted on the internal cement joint, used to waterproof and seal any gaps and holes on the joint area.



Features:

 1.Can pass leaking test

 Can confirm the sealing property of the construction joint at scene

Grout only when the joint leaking

 2.Hose can be unlimited re-injected

 If there are still crack or new cracks, hose can be grouted again, effectively reduce the complicated process of changing tools

 3.Rigid core  Won't be pressed flat under concrete pressure so as to make the use of the grouting unobstructed

 4. Resistance to chemical corrosion

 Won't be corroded when contacting polyurethane, ethylene resin, epoxy resin or cement, the material is durable, Do not contain metal

5.Flexibility

Expediently placed in the corner, no need to cut and connect.



Application:

 Subway, tunnel, Water and sewage treatment plants, Swimming pool and water amusement park, Nuclear power station, The dam, lock, canals, reservoir and ditch, Primary and secondary cofferdam facilities, Bridge,   Commercial and industrial buildings, garage, stadium, Aquarium, tank and similar structure .





Installation method:



LW repeatable injection pipe installation length can reach up to 10 meters, which include the fiber reinforced PVC end. If you need longer, please contact Beijing Lang Wei times science and technology co.,ltd.;

In central parts, every 20 -- 25 cm, use special plastic clip or pipe clamp (see figure 1 and figure 2) to fix LW repeatable injection pipe on flat and smooth cement plane;

Plastic injection hose For sealing construction joints

Cover at least 2cm cement overlay;



Not to install in ways of bend or limitation, and should not be connected in reinforcing bars as building support





Distance between two parallel injection pipes is at least 5 cm

Connect grouting pump at the end of the PVC emissions tube For future grouting, The fiber reinforced PVC pipe ends should be exposed to convenient, accessible place. Use terminal box, shoot to nail gun or directly extend fiber reinforced pipe to the cement external (see chart 3);



Plastic injection hose For sealing construction joints

In many practical applications, it requires the injection pipe cross each other. The intersection parts must maintain close contact with concrete; Discharge outlet part can overlap (see chart 1);

Extend the fiber reinforced discharge outlet about 10cm into the box when junction box used.

Plastic injection hose For sealing construction joints





  Two models are alternative:

Model

Internal diameter

External diameter

Out hole

Gap between holes

LW1

6mm

19mm

3mm

20mm

LW2

10mm

24mm

5mm

25mm





Note:

 LW 1 Used for all standard building joint;

 LW 2 If need more long injection pipe according to design reasons or if the upcoming cement mortar (Portland cement and mortar mixture) grouting, namely, as to design and application problems, please call Beijing Lang Wei times science and technology co., led.

  Storage:

Stored in a cover of place, avoid oil, dirt, concrete rubble, etc. getting into the hose.

 Quality guarantee period:Permanent preservation according to the recommended way, in the seal, original conditions.

Reusable Grouting Hose - 1.JPG361057166.JPG

  IMG_0542.JPG II.jpgIMG_0928.JPGIMG_0975_conew1.jpgIMG_0977.JPGinjection hose  onew1.jpgIMG_1105.JPGIMG_2559.JPG

Plastic injection hose For sealing construction joints

Plastic injection hose For sealing construction joints
