Grout Pump Machine, Resin Injection Pump

FOB Reference Price:Get Latest Price
US $300-400 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Beijing, China (Mainland)
Brand Name:
LW
Model Number:
LW01
After-sales Service Provided:
Engineers available to service machinery overseas
Other Name:
high pressure grouting machine
Applicable materials:
Epoxy resin/ polyurethane,acrylate grout
Name:
Grout Pump Machine, Resin Injection Pump
Type:
Electricl
Application:
Civil Engineering
Color:
Customized
Product name:
Grout Pump Machine, Resin Injection Pump
Power:
5.5kw
Certification:
ISO
Usage:
grouting
Supply Ability
Supply Ability:
150 Set/Sets per Month
Packaging & Delivery
Packaging Details
grout pump is packing: one set in a carton
Port
Tianjin/Shanghai port
Lead Time :
Shipped in 5 days after payment

Professional Grout Pump Machine, Resin Injection Pump

Product Description



Product Introduction:

The electric high pressure injection pump is a professional machine used for high pressure chemical grouting, which works with both single and double component grouting material. It can produce high pressure itself. When there are leakage-stop constructions on engineering include architecture, underground, water conservancy, environment protection, civicism, subway, tunnel, culvert, crack reinforcement, it is the preferred equipment.



Specifications:

   PU foam agent, Epoxy resin. Polyurethane, acrylic resin injection pump

1. Portable,high pressure

2. Output pressure up to 11000psi(max)

3. Easy operation,safe

4. Cheap



Main data:

  LW-01

Net weight

7kg

Maximum output pressure

10000psi

Pressure of starting again

less than 7500psi

Safe range of high-pressure hose

less than 1500

Safe range of switch valve

less than 15000psi

Packing size

32*20*49CM

Power

110v,220v

the length of hose

5m



Application:

Leak-stoppage, waterproof & reinforcement for concrete structure, such as

basement, floor, the second joints, subway, tunnel, Continuous wall, cracks,

water seepage, etc.



Grout Pump Machine, Resin Injection Pump



Epoxy and Resin injection pump for concrete repairing , concrete repair injection pumps



Single Component Injection Pump It is the professional machine which is applied in the structure perfusion, equipped with super pressure. To solve out the inconvenience of the carrier, it is very light and it is the best choice of stanch worker. Speedy Construction : can be advanced to 5000PSI in a few seconds, and the working time will be shorter than other machine.

Low gross, easy to carry.

Simple maintenance:can be fixed without special training, to avoid the delay for the machine fixing.

Standing Pressure: can be affused into the small slot effetively, and envelop the leaking.



grout pump specifications:



Gross: 9 Kg Power: 560w single-phase alternating current 220v/50Hz

Max Output Pressure: 11000 PSI

Star-up: < 7500 PSI

Safety Scope of High-pressure pipe: < 14000 PSI

Safety Scope of On-off Valve: < 18000 PSI

Safety Scope of Butter Head: < 16000 PSI

Standard Specification:

Certifications



Trade Shows



Company Information



         LangWei Conchem is a fast growing international manufacturer of construction chemicals with plants in Beijing, China. The company is specialized in preventative and remedial waterproofing products.



        Preventative waterproofing products are wildly used during new construction and are usually installed by the general contractor. Examples are bentonite strips, hydrophilic mastics and rubbers, which swell in contact with water and hence block water ingress, injection hoses, which can be injected at a later stage to block water and finally cementitious coatings for basement waterproofing and elastomeric membranes for tanks and roofs.



        Remedial waterproofing products are mostly used when major (or minor) water leaks happen at a later stage and are usually applied by specialist applicators. Remedial waterproofing products are also often used during construction of tunnels and other underground constructions to prevent infiltrating water from hindering the normal progress of the works. Examples are injection resins based on Polyurethanes (both 1C and 2C) and Poly-acrylates. These products are also used for Soil and Rock Stabilization, together with Organo-minerals.



        LangWei Conchem also manufactures a series of products for the Protection and Repair of reinforced Concrete. Examples are cementitious grouts and mortars, epoxy injection resins, carbon fibre laminates and epoxy glues.

Application

        LangWei Conchem is specialized in preventative and remedial waterproofing products, which are mostly used in Balcony waterproofing, car part decks, concrete repair and protection, facade waterproofing, flooring systems, injection equipments, packers & accessories, preventative waterproofing, remedial waterproofing, roof waterproofing, sewer rehabilitation, soil injections, tunel applications and so on.
